- Platform
- Engines
- Display
- LED Headlights
- Rear Suspension
- Rear Suspension
- Shocks
- Skis
Explore XTerrain Packages & Specifications
-
Transportation and preparation not included.-
Trail
- On & Off Trail
- Rotax® 850 E-TEC engine
- PPS³ / LFS+ suspension
- KYB PRO 46 HLCR Kashima shocks
- 2.0 in. PowderMax† track
- LED lights, 7.2-in. gauge or 10.25" Color Display
![platinum-silver-satin---evo-red]()
The extreme crossover born to conquer the nastiest of trails and beyond. The new Radien² platform provides improved ergonomics, superior lighting power and the latest 10.25’’ color touchscreen display. The PPS³ / LFS+ suspension with top-of-the-line KYB PRO 46 HLCR Kashima shocks offer the best performance in aggressive riding.
-
Engine
Rotax® 850 E-TEC
-
Rear suspension
PPS³, KYB PRO 46 HLCR Kashima shocks
-
Front suspension
LFS+, 1067 mm ski stance, KYB PRO 46 HLCR Kashima shocks
-
Track
PowderMax† 16 x 146 x 2.0 in.
-
Special features
LED lights, handguards, 7.2-in. gauge or 10.25" Color Display, heavy-duty rear bumper
Engine Engine - 850 E-TEC
Engine details - Liquid-cooled, two-stroke, 3-D R.A.V.E.™
Cylinders - 2
Cylinders & Displacement - 849 cc
Bore - 82 mm
Stroke - 80.4 mm
Maximum engine speed - 7900 RPM
Carburation - Electronic Direct Injection with additional booster injectors
Recommended fuel type - Unleaded
Minimum octane - 91
Fuel tank - 37 L / 9.8 gal
Oil tank capacity (2-stroke) - 3.4 L / 3.6 qt
Power Train Drive clutch type - pDrive™ with clickers
Driven clutch type - QRS
Brake system - Hydraulic brake with braided steel brake line, plastic master cylinder
Dimensions Vehicle Overall Length - 122.8 in
Vehicle Overall Width - 48 in.
Vehicle Overall Height - 50.4 in.
Ski Stance - 42 in.
Track Length x Width x Profile - PowderMax† : 146 x 16 x 2 in.
Suspensions Front suspension - LFS+
Front shock - KYB PRO 46 HLCR Kashima
Rear suspension - PPS³
Center shock - KYB PRO 46 HLCR Kashima
Rear shock - KYB PRO 46 HLCR Kashima
Feature Frame - Radien²
Skis - Blade XC+
Seating - Sport, 1-up
Handlebar - U-type aluminium with hooks, low grab handle
Riser block height - 120 mm
Starter - Electric and manual
Reverse - RER
Heated throttle lever - Standard
Heated grips - Standard
Gauge - 7.2-in. wide digital display
10.25-in Color Display with BRP Connect
Mirrors - Optional
Windshield - Low
Visor Plug front / rear - Front
12V power outlet - Yes, in front compartment
LinQ Attachment - 2 pairs
-
-
Transportation and preparation not included.-
Trail
- On & Off Trail
- Family Fun
- Rotax® 900 ACE Turbo R engine
- PPS³ / LFS+ suspension
- KYB PRO 46 HLCR Kashima shocks
- 1.6 in. Ice Cobra† studded track
- 7.2-in. gauge or 7.8-in. large panoramic display
![platinum-silver-satin---evo-red]()
Ferocious, yet sophisticated extreme crossover snowmobile purpose-built for long distance adventures. Superior ride quality brought by the unique PPS³ / LFS+ suspension meets outstanding performance powered by the Rotax® 900 ACE Turbo R engine.
-
Engine
Rotax® 900 ACE Turbo R
-
Rear suspension
PPS³, KYB PRO 46 HLCR Kashima shocks
-
Front suspension
LFS+, 1067 mm ski stance, KYB PRO 46 HLCR Kashima shocks
-
Track
Ice Cobra studded 15 x 146 x 1.6 in.
-
Special features
Handguards, 7.2-in. gauge or 7.8-in. large panoramic display, Explorer front & rear bumpers, iTC-system
Engine Engine - 900 ACE™ Turbo R
Engine details - Liquid-cooled, four-stroke D.O.H.C., turbocharged
Cylinders - 3
Cylinders & Displacement - 899 cc
Bore - 74 mm
Stroke - 69,7 mm
Maximum engine speed - 7900 RPM
Carburation - EFI
Recommended fuel type - Unleaded
Minimum octane - 91
Fuel tank - 37 L / 9.8 gal
Oil tank capacity (2-stroke) - 3.4 L / 3.6 qt
Power Train Drive clutch type - pDrive™
Driven clutch type - QRS
Brake system - Hydraulic brake with braided steel brake line, plastic master cylinder
Dimensions Vehicle Overall Length - 122.8 in
Vehicle Overall Width - 48 in.
Vehicle Overall Height - 49.6 in.
Ski Stance - 42 in.
Track Length x Width x Profile - PowderMax† : 146 x 15 x 1.6 in.
Suspensions Front suspension - LFS+
Front shock - KYB PRO 46 HLCR Kashima
Rear suspension - PPS³
Center shock - KYB PRO 46 HLCR Kashima
Rear shock - KYB PRO 46 HLCR Kashima
Feature Frame - Radien-X
Skis - Blade XC+
Seating - Sport, 1-up
Handlebar - U-type aluminium with hooks, low grab handle
Riser block height - 120 mm
Starter - Electric
Reverse - Electromechanical
Heated throttle lever - Standard
Heated grips - Standard
Gauge - 7.2-in. wide digital display
Windshield - Low
Visor Plug front / rear - Front
12V power outlet - Yes, in front compartment
LinQ Attachment - 2 pairs
-
-
2024XTERRAIN BRUTAL
Transportation and preparation not included.-
Deep snow
- Steep and deep
- On & Off Trail
- Rotax® 850 E-TEC engine
- EasyRide + rear suspension
- KYB PRO 36 EA-3 R Kashima and KYB 46 Plus Kashima shocks
- 2.4 in. PowderMax† track
- 7.2-in. wide digital display, air radiator with fan, Multi-LinQ plate
![platinum-silver-satin---evo-red]()
Xterrain Brutal is the crossover snowmobile that crushes the conception of impossible. 20x154x2.4’’ track offers insane grip that Rotax® 850 E-TEC transforms to raw driving force. Sporty suspension with KYB shock absorbers tames the most demanding trails. Xterrain Brutal in unstoppable.
-
Engine
Rotax® 850 E-TEC
-
Rear suspension
EasyRide+, KYB 46 Plus Kashima shocks
-
Front suspension
LFS+, 996 mm ski stance, KYB PRO 36 EA-3 R Kashima shocks
-
Track
PowderMax† 20 x 154 x 2.4 in.
-
Special features
Handguards, Brutal seat, 7.2-in. gauge, Explorer front bumper, Multi-LinQ plate, air radiator with fan
Engine Engine - 850 E-TEC
Engine details - Liquid-cooled, two-stroke, 3-D R.A.V.E.™
Cylinders - 2
Cylinders & Displacement - 849 cc
Bore - 82 mm
Stroke - 80.4 mm
Maximum engine speed - 7900 RPM
Carburation - Electronic Direct Injection with additional booster injectors
Recommended fuel type - Unleaded
Minimum octane - 91
Fuel tank - 42 L / 11 gal
Oil tank capacity (2-stroke) - 3.4 L / 3.6 qt
Power Train Drive clutch type - pDrive™ with clickers
Driven clutch type - QRS
Brake system - Hydraulic brake with braided steel brake line, plastic master cylinder
Dimensions Vehicle Overall Length - 127 in.
Vehicle Overall Width - 47.2 in.
Vehicle Overall Height - 48.4 in.
Ski Stance - 39 in.
Track Length x Width x Profile - PowderMax† : 154 x 20 x 2.4 in.
Suspensions Front suspension - LFS+
Front shock - KYB PRO 36 EA-3 R Kashima
Rear suspension - EasyRide +
Center shock - KYB 46 Plus Kashima
Rear shock - KYB 46 Plus Kashima
Feature Frame - Radien-X
Skis - Blade DS+
Seating - Brutal, 1-up
Handlebar - U-type aluminium with hooks, low grab handle
Riser block height - 120 mm
Starter - Electric and manual
Reverse - RER
Heated throttle lever - Standard
Heated grips - Standard
Gauge - 7.2-in. wide digital display
Windshield - Low
Visor Plug front / rear - Front
12V power outlet - Yes, in front compartment
LinQ Attachment - Multi-LinQ plate
-
Download spec sheet
