2023XTERRAIN RE
-
Trail
- On & Off Trail
- Family Fun
- Rotax® 850 E-TEC and 900 ACE Turbo R engines
- PPS³ and LFS+ suspensions
- KYB 46 HLCR Kashima shocks
- 16 x 146 x 2.0 in. PowderMax† track
- Blade XC+ skis, 7.2-in. wide digital display, iTC system with three driving modes (900 ACE Turbo R), Explorer rear and front bumpers
![/content/dam/global/en/lynx/my23/photos/vehicle-line-up/crossover/xterrain/studio/Xterrain-na/LYNX-MY23-Xterrain-RE-3700-850-E-TEC-Viper-Red-LINA-Studio-34FRT-RGB.png]()
![viper-red]()
The extreme crossover snowmobile for demanding trails and deep snow. The PPS³ rear suspension and LFS+ front suspension with high quality KYB 46 Kashima HLCR shock absorbers ensure maximal control in aggressive riding. Engine options are fierce Rotax® 850 E-TEC and infinitely powerful Rotax® 900 ACE Turbo R.
-
Engine
Rotax® 850 E-TEC, Rotax® 900 ACE Turbo R
-
Rear suspension
PPS³ -3700 rear suspension, KYB 46 HLCR Kashima shocks
-
Front suspension
LFS+ front suspension, 1067 mm ski stance, KYB 46 HLCR Kashima shocks
-
Track
PowderMax† 16 x 146 x 2.0 in.
-
Special features
Low windshield, handguards, 7.2-in. wide digital display, Explorer front & rear bumpers, Blade XC+ skis and iTC system with three driving modes (900 ACE Turbo R)
Engine Engine - 850 E-TEC
900 ACE™ Turbo R
Engine details - Liquid-cooled, two-stroke, 3-D R.A.V.E.™
Liquid-cooled, four-stroke D.O.H.C., turbocharged
Cylinders - 2
3
Cylinders & Displacement - 849 cc
899 cc
Bore - 82 mm
74 mm
Stroke - 80.4 mm
69,7 mm
Maximum engine speed - 7900 RPM
Carburation - Electronic Direct Injection with additional booster injectors
EFI
Recommended fuel type - Unleaded
Minimum octane - 91
Fuel tank - 37 L / 9.8 gal
Oil tank capacity - 3.4 L / 3.6 qt
Power Train Drive clutch type - pDrive™ with clickers
Driven clutch type - QRS
Brake system - Hydraulic brake with braided steel brake line, plastic master cylinder
Dimensions Vehicle Overall Length - 122.8 in
Vehicle Overall Width - 48 in.
Vehicle Overall Height - 49.6 in.
Ski Stance - 42 in.
Track Length x Width x Profile - PowderMax† : 146 x 16 x 2 in.
Suspensions Front suspension - LFS+
Front shock - KYB 46 HLCR Kashima
Rear suspension - PPS³ -3700
Center shock - KYB 46 HLCR Kashima
Rear shock - KYB 46 HLCR Kashima
Feature Frame - Radien
Radien-X
Skis - Blade XC+
Seating - Sport, 1-up
Handlebar - U-type aluminium with hooks, low grab handle
Riser block height - 120 mm
Starter - Electric and manual
Reverse - RER
Electromechanical
Heated throttle lever - Standard
Heated grips - Standard
Gauge - 7.2-in. wide digital display
Mirrors - Optional
Windshield - Low
Visor Plug front / rear - Front
12V power outlet - Yes, in front compartment
LinQ Attachment - 2 pairs
-
-
2023XTERRAIN BRUTAL
-
Deep snow
- Steep and deep
- On & Off Trail
- Rotax® 850 E-TEC engine
- EasyRide rear suspension
- KYB 36 and KYB 46 Kashima shocks
- 20 x 154 x 2.5 in. PowderMax† track
- Blade DS+ skis, 7.2-in. wide digital display, air radiator with fan, Multi-LinQ plate, Explorer front bumper
![/content/dam/global/en/lynx/my23/photos/vehicle-line-up/crossover/xterrain/studio/Xterrain-na/LYNX-MY23-Xterrain-Brutal-850-E-TEC-Viper-Red-LINA-Studio-34FRT-RGB.png]()
![viper-red]()
Xterrain Brutal is the crossover snowmobile that crushes the conception of impossible. 20 x 154 x 2.5 in. track offers insane grip that Rotax® 850 E-TEC transforms to raw driving force. Sporty suspension with KYB shock absorbers tames the most demanding trails. Xterrain Brutal in unstoppable.
-
Engine
Rotax® 850 E-TEC
-
Rear suspension
EasyRide rear suspension, KYB 46 Kashima shocks
-
Front suspension
LFS front suspension, 996 mm ski stance, KYB 36 shocks
-
Track
PowderMax† 20 x 154 x 2.5 in.
-
Special features
Low windshield, handguards, Brutal seat, 7.2-in. wide digital display, Explorer front bumper, Multi-LinQ plate, air radiator with fan and Blade DS+ skis
Engine Engine - 850 E-TEC
Engine details - Liquid-cooled, two-stroke, 3-D R.A.V.E.™
Cylinders - 2
Cylinders & Displacement - 849 cc
Bore - 82 mm
Stroke - 80.4 mm
Maximum engine speed - 7900 RPM
Carburation - Electronic Direct Injection with additional booster injectors
Recommended fuel type - Unleaded
Minimum octane - 91
Fuel tank - 42 L / 11 gal
Oil tank capacity - 3.4 L / 3.6 qt
Power Train Drive clutch type - pDrive™ with clickers
Driven clutch type - QRS
Brake system - Hydraulic brake with braided steel brake line, plastic master cylinder
Dimensions Vehicle Overall Length - 127 in.
Vehicle Overall Width - 47.2 in.
Vehicle Overall Height - 48.4 in.
Ski Stance - 39 in.
Track Length x Width x Profile - PowderMax† : 154 x 20 x 2.4 in.
Suspensions Front suspension - LFS
Front shock - KYB 46 HLCR Kashima
Rear suspension - EasyRide
Center shock - KYB 46 Kashima
Rear shock - KYB 46 Kashima
Feature Frame - Radien-X
Skis - Blade DS+
Seating - Brutal, 1-up
Handlebar - U-type aluminium with hooks, low grab handle
Riser block height - 120 mm
Starter - Electric and manual
Reverse - RER
Heated throttle lever - Standard
Heated grips - Standard
Gauge - 7.2-in. wide digital display
Windshield - Low
Visor Plug front / rear - Front
12V power outlet - Yes, in front compartment
LinQ Attachment - Multi-LinQ plate
-
